Double pipe clamp with double-threaded screw / FIXP–PDSD1 is a durable and versatile solution for simultaneous mounting of two installation pipes with direct attachment to the substrate using a double-threaded screw.

What is the product?

The FIXP–PDSD1 is a dual pipe clamp engineered for simultaneous secure mounting of two installation pipes. Constructed from high-strength copolymer, the clamp provides enhanced resistance to mechanical stress and environmental exposure. It accommodates pipes with diameters ranging from 10 mm to 28 mm, compatible with copper, polypropylene (PP), PEX-AL-PEX multilayer, metric, and other pipe types. The integrated double-threaded screw enables direct, stable, and vibration-resistant fixation to structural substrates, eliminating the requirement for additional anchoring hardware.

Advantages

universal application – one clip fits multiple pipe types with various diameters
safe installation – special design prevents arm deformation and enables easy pipe insertion
resistance to operating conditions – temperature range from -10°C to +90°C; high tensile strength
high durability – made from high-strength copolymer with a melting point of 160°C
flexible mounting options – can be fixed using screws, M6 double-threaded bolts, or mounting rails

Type	Double handle
Material	copolymer
Operating range	-10°C to +90°C
Temperature resistance	melting point at 160°C
Variant	white RAL 9002

Index	Diameter	Product dimensions X/ Y/ Z [mm]	Net weight [g]
A-690760	10	41.5x16.5x21	10,4
A-690777	12	50x16x23	12
A-690784	14-15	59x15.5x27.5	13,6
A-690791	16-18	59x15.5x34	15,1
A-690807	20-22	65x15.5x38	17,1
A-690814	25-28	82x16x50.5	25,3
